13CrMo4-5 WN Flange 1.7335 So Flange Forged EN1092-1 Blind Flanges
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | 13CrMo4-5 | Steel Number | 1.7335 |
|---|---|---|---|
| Flange | En1092-1 | Face | RF , FF |
| High Light | 13CrMo4-5 WN Flange,Forged EN1092-1 Flange,EN1092-1 Blind Flanges |
||
Product Description
13CrMo4-5 wn flange ( 1.7335 ) so flange EN1092-1 Blind flanges Forged flanges
| Grade : | 13CrMo4-5 | |||||
| Number: | 1.7335 | |||||
| Classification: | Alloy special steel | |||||
| Density: | 7.85 g/cm ³ | |||||
| Standard: |
|
| According EN 10216-2 chemical composition: 0.1 < C < 0.17; 0.4 < Mn < 0.7; |
| C | Si | Mn | P | S | Cr | Mo | N | Cu |
| 0.08 - 0.18 | max 0.35 | 0.4 - 1 | max 0.025 | max 0.01 | 0.7 - 1.15 | 0.4 - 0.6 | max 0.012 | max 0.3 |
Mechanical properties of steel 13CrMo4-5 (1.7335)
| Nominal thickness (mm): | to 60 | 60 - 100 | 100 - 150 | 150 - 250 |
| Rm - Tensile strength (MPa) | 450-600 | 440-590 | 430-580 | 420-570 |
| Nominal thickness (mm): | to 16 | 16 - 60 | 60 - 100 | 100 - 150 | 150 - 250 |
| ReH - Minimum yield strength (MPa) | 290-300 | 290 | 270 | 255 | 245 |
| KV - Impact energy (J) transverse, | +20° 27 |
| KV - Impact energy (J) longitud., | +20° 40-44 |
| A - Min. elongation at fracture (%) | 19-22 |
Equivalent grades of steel 13CrMo4-5 (1.7335)
| EU EN | USA - | Germany DIN,WNr | Japan JIS | France AFNOR | England BS | Italy UNI | Spain UNE | China GB | Sweden SS | Poland PN | Czechia CSN | Austria ONORM | Russia GOST | Inter ISO | |||||||||||||||||||||||
| 13CrMo4-5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
