1.8953 Slip On Plate Flanges S460NH On Plate Flanges Steel So Flanges Steel Plate Flanges
Product Summary
Grade : S460NH Number: 1.8953 Classification: Structural steel Standard: EN 10210-1: 2006 Hot finished structural hollow sections of non-alloy and fine grain steels. Technical delivery requirements EN 10219-1: 2006 Cold formed welded structural hollow sections of non-alloy and fine grain steels. ...
Product Details
Highlight:
Steel plate flanges S460NH
,Slip On plate flanges S460NH
,1.8953 slip on plate flanges
Material:
1.8953
Steel:
S460NH
Type:
Slip On Plate Flange
Flanges:
So Flanges
Product Description
| Grade : | S460NH | ||
| Number: | 1.8953 | ||
| Classification: | Structural steel | ||
| Standard: |
|
| CEV < 0.53 / 0.55 for thickness 16 / 65 mm |
| C | Si | Mn | Ni | P | S | Cr | Mo | V | N | Nb | Ti | Al | Cu |
| max 0.22 | max 0.6 | 1 - 1.7 | max 0.8 | max 0.035 | max 0.03 | max 0.3 | max 0.1 | max 0.2 | max 0.025 | max 0.05 | max 0.03 | max 0.02 | max 0.7 |
Mechanical properties of steel S460NH (1.8953)
| Nominal thickness (mm): | to 65 |
| Rm - Tensile strength (MPa) | 540-720 |
| Nominal thickness (mm): | to 16 | 16 - 40 | 40 - 65 |
| ReH - Minimum yield strength (MPa) | 460 | 440 | 430 |
| KV - Impact energy (J) | -20° 40 |
| Nominal thickness (mm): | to 65 |
| A - Min. elongation at fracture (%) longitud., | 17 |
| Nominal thickness (mm): | to 65 |
| A - Min. elongation at fracture (%) transverse, | 15 |
