1.0039 Tubes for construction EN 10210 S235JRH Steel Pipes for agricultural machinery and plant construction

Tubes for construction

EN 10210

Hot formed hollow sections of non-alloyed steel
Welded circular, square and elliptical hollow sections
Seamless tubes circular and square

Scope of application Steel construction, engineering,
vehicle construction, agricultural
machinery and plant construction

Manufacturing process
- Seamless
- Welded

with additional normalization or hot
stretched reduced

Material number
and qualities
- unalloyed steel
EN 1.0039 S 235 JRH
1.0149 S 275 JOH
1.0138 S 275 J2H
1.0547 S 355 JOH
1.0576 S 355 J2H
- Fine grained steel
EN 1.0493 S 275 NH
1.0497 S 275 NLH
1.0539 S 355 NH
1.0549 S 355 NLH
1.8953 S 460 NH
1.8956 S 460 NLH

Dimension
OD
- circular 21,3 up to 2.020 mm
(seamless up to 660 mm)
- square 40 × 40 mm up to 400 × 400 mm
- rectangular 50 × 30 mm up to 500 × 300 mm
- elliptical 120 × 60 mm up to 480 × 240 mm
WT
- circular up to 50 mm
- square up to 25 mm
· Delivery length
- seamless 4 to 7 m or double lengths
- welded 6 to 15 m, special lengths up to 24 m
on request
· Exact length on request
