3inch 150 Blind Flange S355J2G3 Material ASME B16.48 Standard Spade Flange
Product Summary
STANDARD FLANGE 3” 150 BLIND SPADE FF ASME B16.48 Material S355J2G3. Features blind flange type with 150 pressure rating. Certified with SIL, GB/T45001-2020 IDT ISO45001:2018, GB/T9001-2016 IDT ISO9001:2015 standards.
Product Details
Highlight:
3 inch blind flange S355J2G3
,150 blind spade flange ASME B16.48
,welding neck flange with warranty
Material:
S355 J2G3
Size:
3inch
Pressure:
150
Type:
Blind Flanges
Product Description
STANDARD FLANGE 3” 150 BLIND SPADE FF ASME B16.48 Material S355J2G3
Flange Material Specifications
| Material Type | Specifications |
|---|---|
| Carbon Steel | ASTM A105, ASTM A350 LF1, LF2, CL1/CL2, A234, S235JRG2, P245GH, P250GH, P280GHM 16MN, 20MN, 20# |
| Stainless Steel | ASTM A182, F304/304L, F316/316L |
| Alloy Steel | ASTM A182 A182 F12, F11, F22, F5, F9, F91, etc. |
Flange Standards
| Standard | Pressure Classes |
|---|---|
| ANSI | Class 150 Flanges - Class 2500 Flanges |
| DIN | 6Bar, 10Bar, 16Bar, 25Bar, 40Bar |
| JIS | 5K Flanges - 20K Flanges |
| UNI | 6Bar, 10Bar, 16Bar, 25Bar, 40Bar |
| EN | 6Bar, 10Bar, 16Bar, 25Bar, 40Bar |
Flange Types
- Welding Neck Flange
- Slip On Flange
- Blind Flange
- Long Welding Neck Flange
- Lap Joint Flange
- Socket Welding Flange
- Threaded Flange
- Flat Flange
Certifications
SIL, GB/T45001-2020 IDT ISO45001:2018, GB/T9001-2016 IDT ISO9001:2015
International Material Equivalents
EU EN
S355J2(+N) (1.0570)
USA
1024
Germany DIN, WNr
1.0570, St52-3, St52-3N
Japan JIS
SM490, SM490C, SS490C
France AFNOR
E36-3
England BS
50D
European old EN
Fe510D1, S355J2G3
Italy UNI
Fe510, Fe510D
Belgium NBN
AE355D
Spain UNE
AE355D
China GB
16Mn
Sweden SS
2135-01
Poland PN
G355
Finland SFS
Fe52D
Austria ONORM
St510D, St52F
Norway NS
NS12-153
Russia GOST
17G1S, 17GS, S345
Inter ISO
Fe510D
Portugal NP
Fe510-D
India IS
Fe540WHT
