Flange Tube Sheet for Heat Exchangers Ø1270 mm Thickness 148 mm Material A182 F316L
Product Summary
SPECIAL FLANGE TUBE SHEET FOR HEAT EXCHANGERS Ø1270 mm Thickness 148 mm Material A182 F316L. Certified to ASTM A182/A240 & ASME SA182/SA240 standards with EN 10204/3.1B test certificates. Suitable for bitumen upgraders, heavy oil refineries, nuclear power, petrochemicals, and acid applications.
Product Details
Highlight:
A182 F316L welding neck flange
,1270mm heat exchanger tube sheet
,148mm thick flange tube sheet
Material:
A182 F316L
Type:
Tube Sheet
Size:
1270/48mm
Flange:
Tube Sheet Flanges
Product Description
SPECIAL FLANGE TUBE SHEET FOR HEAT EXCHANGERS Ø1270 mm Thickness 148 mm Material A182 F316L
Product Specifications
Standard Specifications: ASTM A182 / A240 & ASME SA182 / SA240
| Dimensions | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Size Range | 1/2" (15 NB) to 48" (1200NB) DN10~DN5000 or special sizes |
| Connect Type/Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
Pressure Ratings:
- ANSI: Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS
- DIN: 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64
- JIS: 5K, 10K, 16K, 20K, 30K, 40K, 63K
- UNI/EN: 6Bar 10Bar 16Bar 25Bar 40Bar
Standards Compliance
- BS (British Standard)
- DIN, EN (European)
- ASA/ANSI/ASME B16.5/16.36/16.47A/16.47B
- B16.47 Series A & B
- B16.48
- BS4504
- BS 10
- EN-1092
- GOST Flange
- MSS S44
- ISO 70051
- JIS B2220
- BS1560-3.1
- API 7S-15
- API 7S-43
- API 605
- EN 1092
Manufacturing & Quality
Most Common Types: Forged / Threaded / Screwed / Plate
Production Technique: Forged, Heat treated and machined
Test Certificates:
- EN 10204/3.1B
- Raw Materials Certificate
- 100% Radiography Test Report
- Third Party Inspection Report, etc.
Applications & Markets
Uses & Applications:
- Bitumen upgraders
- Heavy oil refineries
- Nuclear power (mostly seamless)
- Petrochemicals and acids
Export To: Dubai, UAE, Indonesia, Ireland, Malaysia, Singapore, Egypt, Ukraine, Saudi Arabia, Spain, Canada, USA, Brazil, Thailand, Korea, Iran, Oman, Peru, etc.
ASTM A182 F316L Chemical Composition
| SS | Mn | C | Si | P | S | Cr | Mo | Ni | N |
|---|---|---|---|---|---|---|---|---|---|
| A182 F316 | 2 max | 0.08 max | 1.0 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 11.00 - 14.00 | 67.845 min |
| A182 F316L | 2 max | 0.035 max | 1.00 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 10.00 - 14.00 | 68.89 min |
A182 F316L Stainless Steel Mechanical Properties
| SS | Density | Melting Range | MPa-Psi Tensile Strength | MPa-Psi Yield Strength (0.2% Offset) | % Elongation |
|---|---|---|---|---|---|
| F316/ SS 316 | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi - 75000, MPa - 515 | Psi - 30000, MPa - 205 | 35 % |
| F316L/ SS 316L | 8.0 g/cm3 | 1399 °C (2550 °F) | Psi - 75000, MPa - 515 | Psi - 30000, MPa - 205 | 35% |
