36inch A350 LF2 CL.1 600 Rating Welding Neck Flange with Reinforced LWN RF and Pad Connection
Product Summary
SPECIAL FLANGE 36”600 REINFORCED LWN RF L=697mm WITH PAD CONNECTION made from A350 LF2 CL.1 carbon steel. Features moderate strength, impact toughness, and suitability for cold temperature service. Compliant with ASME B16.5 and EN1092 standards, with good machinability and weldability.
Product Details
Highlight:
36 inch reinforced welding neck flange
,A350 LF2 Class 1 flange with pad
,697mm long RF welding neck flange
Material:
A350 LF2 CL.1
Size:
36inch
Rating:
600
LWN:
L=697MM
Product Description
SPECIAL FLANGE 36" 600 REINFORCED LWN RF L=697mm WITH PAD CONNECTION
Material Specification
Material: A350 LF2 CL.1 - Carbon Steel
Product Overview
ASTM A350 Grade LF2 is a general carbon steel typically supplied in Normalised, Normalised and Tempered, or Quench and Tempered condition. This material features moderate strength and impact toughness, making it ideal for flange and fitting manufacturing, as well as applications requiring cold temperature service where corrosion resistance is not critical.
| Standards | ASME B16.5, EN1092 |
|---|---|
| Material | ASTM A105, A350, A266 etc |
| Size | 1/2" - 24" |
| Surface Treatment | Anti-rust oil, clear lacquer, Black lacquer, Yellow lacquer, Hot-dipped Galvanized |
Manufacturing Process
Forging
Forging temperature range: 900 – 1200°C. Soak times should be minimized to prevent heavy scaling while ensuring the center reaches furnace temperature. Post-forging, pieces should cool in still air.
Heat Treatment
- Normalising: Heat to 860-920°C for duration based on ruling section, then air cool (if required)
- Hardening: Heat to 890-960°C for duration based on ruling section, then water quench
- Tempering: Re-heat to minimum 590°C as required for final properties. Hold for duration based on ruling section and cool in still air
Machinability
ASTM A350 LF2 offers good to very good machinability depending on condition. Standard machining operations including sawing, turning, broaching, and milling can be performed effectively using manufacturer-recommended speeds and feeds.
Weldability
ASTM A350 LF2 is readily weldable using any standard welding technique.
