X6CrNiMo17-13-2 Heat Resistant SS Pipes EN 10216-5 1.4918 Stainless Steel Pipe
Product Summary
Grade : X6CrNiMo17-13-2 Number: 1.4918 Classification: Austenitic creep resisting steel Density: 8 g/cm ³ Standard: EN 10216-5: 2014 Seamless steel tubes for pressure purposes. Technical delivery conditions. Stainless steel tubes EN 10088-1: 2005 Stainless steels. List of stainless steels Chemical ...
Product Details
Highlight:
Heat Resistant SS Pipes
,1.4918 Stainless Steel Pipe
Material:
X6CrNiMo17-13-2
Steel Number:
1.4918
Type:
Stainless Steel Pipes
Standard:
En10216-5
Product Description
| Grade : | X6CrNiMo17-13-2 | ||
| Number: | 1.4918 | ||
| Classification: | Austenitic creep resisting steel | ||
| Density: | 8 g/cm ³ | ||
| Standard: |
|
Chemical composition % of steel X6CrNiMo17-13-2 (1.4918): EN 10216-5-2014
| C | Si | Mn | Ni | P | S | Cr | Mo | N |
| 0.04 - 0.08 | max 0.75 | max 2 | 12 - 14 | max 0.035 | max 0.015 | 16 - 18 | 2 - 2.5 | max 0.1 |
Mechanical properties of steel X6CrNiMo17-13-2 (1.4918)
| Rm - Tensile strength (MPa) (+AT) | 490-690 |
| Rp0.2 0.2% proof strength (MPa) (+AT) | 205 |
| KV - Impact energy (J) longitud., (+AT) | +20° 100 |
| KV - Impact energy (J) transverse, (+AT) | +20° 60 |
| A - Min. elongation at fracture (%) longitud., (+AT) | 35 |
| A - Min. elongation at fracture (%) transverse, (+AT) | 30 |
Properties of steel X6CrNiMo17-13-2 (1.4918)
| Resistance to intergranular corrosion - no |
