EN 10216-2 Alloy Seamless Steel Pipes 1.0345 P235GH Alloy Steel Pipes

  • EN 10216-2 Alloy Seamless Steel Pipes 1.0345 P235GH Alloy Steel Pipes
  • EN 10216-2 Alloy Seamless Steel Pipes 1.0345 P235GH Alloy Steel Pipes
  • EN 10216-2 Alloy Seamless Steel Pipes 1.0345 P235GH Alloy Steel Pipes
  • EN 10216-2 Alloy Seamless Steel Pipes 1.0345 P235GH Alloy Steel Pipes

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material P235GH Steel Number 1.0345
Standard EN 10216-2 Type Alloy Seamless Pipes
High Light

EN 10216-2 Alloy Seamless Steel Pipes

,

P235GH Alloy Steel Pipes

,

1.0345 Alloy Steel Pipes
Leave a Message
Product Description
Product Name
Seamless Steel Pipe
Standard
GB AISI ASTM DIN EN JIS
Thickness
0.5-60mm or as required
Outer Diameter
6mm- 1200mm or as required
Surface
Electro-galvanizing, hot-dip galvanizing, black or as required
Length
1m-12m or as required
Material
10MoWVNb, 15MnV, 09Mn2V,20# /45#/ Q195/Q235/Q345/S235/S275/S355/SS400 etc
Shape
Round.Square.Rectangle
Technique
Hot rolled or Cold rolled
Package
Standard sea-worthy packing
Payment Term
Ex-work, FOB, CFR, CIF, or as Requirement
Exports
Russia,Uzbekistan,Kazakhstan,Ukraine Singapore,Indonesia, Canada, African countries Brazil, Brunei ,Thailand,Malaysia, Viet
,Philippines, India etc.
Container

Size
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High),20-25 Metric ton 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High),20-26 Metric
ton 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High),20-26 Metric ton
Payment terms
T/T, L/C, Western Union



Grade : P235GH
Number: 1.0345
Classification: Non-alloy quality steel
Density: 7.85 g/cm ³
Standard:
EN 10028-2: 2009 Flat products made of steels for pressure purposes. Non-alloy and alloy steels with specified elevated temperature properties
EN 10216-2: 2014 Seamless steel tubes for pressure purposes. Technical delivery conditions. Non-alloy and alloy steel tubes with specified elevated temperature properties
EN 10217-5: 2002 Welded steel tubes for pressure purposes. Submerged arc welded non-alloy and alloy steel tubes with specified elevated temperature properties
EN 10217-2: 2002 Welded steel tubes for pressure purposes. Electric welded non-alloy and alloy steel tubes with specified elevated temperature properties
EN 10253-2: 2007 Butt-welding pipe fittings. Non alloy and ferritic alloy steels with specific inspection requirements
EN 10273: 2007 Hot rolled weldable steel bars for pressure purposes with specified elevated temperature properties



Chemical composition % of steel P235GH (1.0345): EN 10028-2-2003
C Si Mn Ni P S Cr Mo V N Nb Ti Al Cu -
max 0.16 max 0.35 0.6 - 1.2 max 0.3 max 0.025 max 0.015 max 0.3 max 0.08 max 0.02 max 0.012 max 0.02 max 0.03 max 0.02 max 0.3 Cr+Cu+Mo+Ni < 0.7


Mechanical properties of steel P235GH (1.0345)

Nominal thickness (mm): to 100 100 - 150 150 - 250
Rm - Tensile strength (MPa) (+N) 360-480 350-480 340-480

Nominal thickness (mm): to 16 16 - 40 40 - 60 60 - 100 100 - 150 150 - 250
ReH - Minimum yield strength (MPa) (+N) 235 225 215 200 185 170

KV - Impact energy (J) transverse, (+N) -20°
27		 0°
27		 +20°
40
KV - Impact energy (J) longitud., -10°
28		 0°
40		 +20°
47

A - Min. elongation at fracture (%) (+N) 24-25


Equivalent grades of steel P235GH (1.0345)
Warning! Only for reference
EU
EN		 USA
-		 Germany
DIN,WNr		 Japan
JIS		 France
AFNOR		 England
BS		 Italy
UNI		 Belgium
NBN		 Spain
UNE		 China
GB		 Sweden
SS		 Poland
PN		 Czechia
CSN		 Finland
SFS		 Austria
ONORM		 Russia
GOST		 Inter
ISO		 India
IS
P235GH
A285
A285Gr.C
1.0345
ASt35
HI
StE255
SB410
SGV410
SPV235
SPV24
A37AP
A37CP
141-360
161Gr.360
Fe360-1KG
Fe360-1KW
FeE235
D37-1.2
E37-1.2
A37RCI
20
1330
1330-01
St36K
11364
11366
Fe37BP
St35KW
12k
P3
Grade1
