15NiMn6 Slip on plate flanges EN 10222-3 so flanges 1.6228 Steel slip on plate flanges
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | 15NiMn6 | Standard | EN1092-1 Type 01 |
|---|---|---|---|
| Steel Number | 1.6228 | Type | Steel Slip On Plate Flanges |
Product Description
| Grade : | 15NiMn6 | ||
| Number: | 1.6228 | ||
| Classification: | Alloy special steel | ||
| Standard: |
|
| Cr+Cu+Mo < 0.5% |
| C | Si | Mn | Ni | P | S | V |
| max 0.18 | max 0.35 | 0.8 - 1.5 | 1.3 - 1.7 | max 0.025 | max 0.01 | max 0.05 |
Mechanical properties of steel 15NiMn6 (1.6228)
| Nominal thickness (mm): | to 80 |
| Rm - Tensile strength (MPa) (+N) | 470-640 |
| Nominal thickness (mm): | to 30 | 30 - 50 | 50 - 80 |
| ReH - Minimum yield strength (MPa) (+N) | 355 | 345 | 335 |
| KV - Impact energy (J) longitud., (+N) | +20° 65 |
0° 65 |
-20° 65 |
-40° 60 |
-50° 50 |
-60° 50 |
-80° 40 |
| KV - Impact energy (J) transverse, (+N) | +20° 50 |
0° 50 |
-20° 45 |
-40° 40 |
-50° 35 |
-60° 35 |
-80° 27 |
| Nominal thickness (mm): | to 80 |
| A - Min. elongation at fracture (%) (+N) | 20-22 |
Equivalent grades of steel 15NiMn6 (1.6228)
| EU EN |
France AFNOR |
|
| 15NiMn6 |
|
