P285NH welding neck flanges EN 10222-4 blind pipe flanges P275NH forged steel flanges EN 10028-3 steel flange1.0487
Product Summary
Grade : P285NH Number: 1.0477 Classification: Non-alloy steel Standard: EN 10222-4: 1999 Steel forgings for pressure purposes. Weldable fine-grain steels with high proof strength Chemical composition % of steel P285NH (1.0477): EN 10222-4-1999 C Si Mn Ni P S Cr Mo V N Nb Al Cu - max 0.18 max 0.4 0.6 ...
Product Details
Highlight:
P285NH welding neck flanges EN 10222-4
,P275NH forged steel flanges EN 10028-3
,Blind pipe flanges steel flange1.0487
Material:
P285NH
Standard:
EN1092-1 Type 01
Type:
Welding Neck Flange
Flange:
Forged Steel Flanges
Product Description
| Grade : | P285NH | |
| Number: | 1.0477 | |
| Classification: | Non-alloy steel | |
| Standard: |
|
| C | Si | Mn | Ni | P | S | Cr | Mo | V | N | Nb | Al | Cu | - |
| max 0.18 | max 0.4 | 0.6 - 1.4 | max 0.3 | max 0.025 | max 0.015 | max 0.3 | max 0.08 | max 0.05 | max 0.02 | max 0.03 | 0.02 - 0.06 | max 0.2 | Nb+V < 0.05 |
Mechanical properties of steel P285NH (1.0477)
| Rm - Tensile strength (MPa) | 370-510 |
| ReH - Minimum yield strength (MPa) | 205-285 |
| KV - Impact energy (J) longitud., (+N) | +20° 55 |
0° 47 |
-20° 40 |
-40° 28 |
| KV - Impact energy (J) transverse, (+N) | +20° 40 |
0° 34 |
| A - Min. elongation at fracture (%) longitud., | 22-24 |
| A - Min. elongation at fracture (%) transverse, | 21-23 |
