1.0352 welding neck flanges P245GH WN flange EN1092-1 Type 11 wn flanges Steel forged WN FLANGES
Product Summary
1.0352 welding neck flanges P245GH WN flange EN1092-1 Type 11 wn flanges Grade : P245GH Number: 1.0352 Classification: Non-alloy steel Standard: EN 10222-2: 2000 Steel forgings for pressure purposes. Ferritic and martensitic steels with specified elevated temperature properties Chemical composition ...
Product Details
Highlight:
P245GH welding neck flanges
,EN1092-1 Type 11 WN flanges
,steel forged welding neck flanges
Material:
1.0352
Material Number:
P245GH
Type:
Wn Flange
Flange:
RF, FF
Product Description
1.0352 welding neck flanges P245GH WN flange EN1092-1 Type 11 wn flanges
| Grade : | P245GH | |
| Number: | 1.0352 | |
| Classification: | Non-alloy steel | |
| Standard: |
|
| C | Si | Mn | P | S |
| 0.08 - 0.2 | max 0.4 | 0.5 - 1.3 | max 0.025 | max 0.015 |
Mechanical properties of steel P245GH (1.0352)
| Rm - Tensile strength (MPa) | 410-530 |
| ReH - Minimum yield strength (MPa) | 220-245 |
| KV - Impact energy (J) longitud., | +20° 32 |
| KV - Impact energy (J) transverse, | +20° 27 |
| A - Min. elongation at fracture (%) longitud., | 25 |
| A - Min. elongation at fracture (%) transverse, | 23 |
