(S)A350 LF2 Weld Neck Flanges SCH80 300LBS A350 LF3 30 Inch Flange
Trading Properties
Minimum Order Quantity:
1 pcs
Price:
0.3 usd/pcs
Payment Terms:
L/C, D/A, D/P, T/T, Western Union,
Supply Ability:
10000 pcs in stock
Product Summary
(S)A350 LF2, LF3 welding neck flanges A350 Lf3 steel flange 30 inch sch80 300lbs weld neck flanges ize 1/2"-160" Type Weld Neck, Slip-On, Blind, Socket Weld, Lap Joint, Threaded, Orifice Flange Swivel Flange, Spectacle Blind,Etc. Standard ANSI, ASME ,MSS, API, DIN, JIS, BS. AWWA and GB Class ANSI ...
Product Details
Highlight:
A350 LF2 Weld Neck Flanges
,SCH80 Weld Neck Flanges
,A350 LF3 30 Inch Flange
Material:
A350 LF2, LF3
Standard:
EN1092-1 Type 01
Type:
Welding Neck Flanges
Size:
30inch Sch80
Product Description
(S)A350 LF2, LF3 welding neck flanges A350 Lf3 steel flange 30 inch sch80 300lbs weld neck flanges
| ize | 1/2"-160" | |
| Type |
Weld Neck, Slip-On, Blind, Socket Weld, Lap Joint, Threaded, Orifice Flange Swivel Flange, Spectacle Blind,Etc. |
|
| Standard | ANSI, ASME ,MSS, API, DIN, JIS, BS. AWWA and GB | |
| Class | ANSI 150LBS-2500LBS | |
| DIN PN6-PN160 | ||
| BS PN0.25-PN25 PN2.0-PN42.0 | ||
| JIS 5K-30K | ||
| Materials | Carbon Steel | ASTM:SA105N/A105 |
| Low Temperature Carbon Steel: ASTM SA350 LF2 | ||
| High Strength Steel: ASTM SA694 F42/46/52/56/60/65 | ||
| Stainless Steel | ASTM A182 F304/304L/316/316L | |
| Alloy Steel | ASTM A182 F1/F5/F9/F11/F22/F91/Etc. | |
| Duplex stainless steel | ASTM A182 F51/F53/F55/F60 | |
| Nicke alloys | Nickel 200, Monel 400, Inconel 600/625, Incoloy 825/800 | |
| Cu-Ni | 90/10,70/30 | |
| Process | Free forging, plate cutting. | |
| Printing | Carbon steel and alloy steel with yellow print, black print, oil or zinc. | |
| Packing | sea worthy plywooden case, wooden pallet | |
| Delivery | Usually within one month after receiving the formal order . | |
| Inspection | Factory in-house or Third Party inspection available upon requests. | |
| We can also manufacture special application flanges and forgings that customers require. | ||
