Product Details:
Place of Origin: China
Brand Name: Best
Certification: API /CE / TUV/ ISO
Model Number: 1/2''-48''
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: 11 usd/pcs
Packaging Details: Wooden cases, Pallets or as customer's requirements
Delivery Time: 5-8 working days
Payment Terms: L/C /TT
Supply Ability: 100000Ton/Year
Detailed Product Description
Material: Inconel 600 N06600 Inconel 690 N06690 Technics: In Stainless Steel And Exotic Alloys
Thickness: Sch10---xxs Certificates: API/CE/ ISO /TUV
Third Inspection: BV/SGS Color: Typical Fittings
High Light:

stainless steel pipe flange


stainless steel pipe joints

Product Name :



 ALLOY 500 (UNS N05500)
− Nickel-copper alloy 500 combines the excellent corrosion resistance characteristic of alloy 400 with the added advantages of greater strength and hardness. The increased properties are obtained by adding aluminum and titanium to the nickel-copper base, and by heating under controlled conditions so that submicroscopic particles of Ni3 (Ti, Al) are precipitated throughout the matrix. The thermal processing used to effect precipitation is commonly called age hardening or aging.
− The corrosion resistance of alloy 500 is substantially equivalent to that of alloy 400 except that, when in the age-hardened condition, alloy 500 has a greater tendency toward stress-corrosion cracking in some environments.
− Alloy 500 has been found to be resistant to a sour-gas environment. After 6 days of continuous immersion in saturated (3500 ppm) hydrogen sulfide solutions at acidic and basic pH's (ranging from 1.0 to 11.0), U-bend specimens of age- hardened sheet showed no cracking. There was some tightly adherent black scale. Hardness of the specimens ranged from 28 to 40 Rc.
− The combination of very low corrosion rates in high-velocity sea water and high strength make alloy 500 particularly suitable for shafts of centrifugal pumps in marine service. In stagnant or slow-moving water, fouling may occur followed by pitting, but this pitting slows down after a fairly rapid initial attack.



Nickel Alloys 400
− Nickel-copper alloy 400 is a solid-solution alloy that can be hardened only by cold working. It has high strength and toughness over a wide temperature range and excellent resistance to many corrosive environments.
Typical Applications
− Alloy 400 is widely used in many fields, especially marine and chemical processing. Typical applications are valves and pumps; pump and propeller shafts; marine fixtures and fasteners; electrical and electronic components; springs; chemical processing equipment; gasoline and fresh water tanks; crude petroleum stills; process vessels and piping; boiler feed water heaters and other heat exchangers; and deaerating heaters



a. The ranges shown are composites for various product sizes and therefore are not suitable for specification purposes. Hardness values are suitable. For specification purposes providing tensile properties are not also specified.
b. Properties on request.
c. Properties shown are for sizes from 0.032 to 0.250 in diameter. Properties for other sizes may vary from these
Typical Applications
− Typical applications for alloy 500 are pump shafts and impellers; doctor blades and scrapers; oil well drill collars and instruments; electronic components; springs; and valve trim.
Alloy E52100
− This high carbon, chromium alloy is stocked in the annealed condition.
− This grade is manufactured by the electric furnace process. Typically the quenched hardness is 62 to 66 HRC depending mainly upon section thickness
Typical Applications
− Grade E52100 is used primarily for races and balls or rollers of rolling-element (anti-friction) bearings. The grade is also suitable for parts requiring high hardness and wear resistance
Typical Mechanical Properties (Annealed)
− Yield – 85,000 psi
− Tensile – 105,000 psi
− Elongation – 17%
− Reduction Area – 50%
− BHN at surface– 228

Typical Fittings in Stainless Steel and Exotic Alloys Inconel 600 N06600 Inconel 690 N06690


Plate Types
Carbon & HSLA
Alloy – Commercial Grades, Military Armor,
Aircraft Quality, Tool Steel
Duracorr® (12% Chromium Stainless)
Cut-To-Length Plate
Floor Plate (Sure-Foot®)
Range – Most Complete Size Range
Carbon/HSLA – 3/16" to 30"
Alloy – 1/8" to 15"
Widths – up to 195" wide
Lengths – up to 1525" and longer
Pattern weights – up to 100,000 lbs.
Refer to size charts in back of this guide
Multiple Rolling Locations
Burns Harbor, IN
Coatesville and Conshohocken, PA
Melting Facilities
Riverdale, IL, Indiana Harbor, IN,
Cleveland, OH and Burns Harbor, IN
Blast Furnaces/Basic Oxygen Furnaces
6" or 10" Strand Cast Slabs
Coatesville, PA
Electric Furnace Melting
9" or 12" Strand Cast Slabs; Bottom Poured Ingot Casting
Ladle Refining/Low Sulfur Calcium Inclusion Shape Control
Vacuum Degassing
VOD Unit – Duracorr® Stainless Melting
Rolling Mills
Burns Harbor, IN - 3/16" to 4", up to 150" wide
TMCP (Thermal-Mechanical Controlled Processing)
Precise Weight Plate
Coatesville, PA – 3/16" to 30", up to 195" wide
Conshohocken, PA
1/8" to 1" Alloy and
3/16" to 2" Carbon, up to 100" wide
Discrete and Coil
Heat Treatment
Normalizing, Normalize and Temper
Quench & Temper
Annealing, Spherodize Anneal
Stress Relieving
Special Non-Standard Cycles
Tensile, CVN Impacts, Drop Weight
Through Gauge Testing, Dynamic Tear
HIC Testing (Hydrogen Induced Cracking)
Cleanliness (Aircraft Quality)
Ultrasonic Testing, Step-Cooling
Magnetic Particle Testing
Quick Plate Program
Coatesville and Conshohocken, PA
See Daily Inventory Listings
Plate Coils
84" to 96" Wide
3/16" to 5/8" Thick
Carbon and HSLA
Flame Cutting
Oxy-fuel and Plasma
Circles, Rings, Sketches, Strips
Special Plate And Flamecut Tolerances
Width and Length
Surface Preparation
Mill Edge
Improved Customer Yields
ISO 9001:2008, ABS, PED
ISO 14001:2004
ISO 18001:2007

1.Product information of steel elbow

Brand Name Best Pipeline
Product Name 90D Elbow
Place of Origin Shanghai China (Mainland)



Carbon steel(ASTM A234WPB,,A234WPC,A420WPL6.

Stainless steel(ASTM A403 WP304,304L,316,316L,904l,321. 1Cr18Ni9Ti, 00Cr19Ni10,
00Cr17Ni14Mo2, ect.)

Alloy Steel:A234WP12,A234WP11,A234WP22,A234WP5,


Carbon steel:St37.0,St35.8,St45.8
Stainless steel:1.4301,1.4306,1.4401,1.4571
Alloy steel:1.7335,1.7380,1.0488(1.0566)


Carbon steel:PG370,PT410
Stainless steel:SUS304,SUS304L,SUS316,SUS316L,SUS321
Alloy steel:PA22,PA23,PA24,PA25,PL380


10#,20#,20G,23g,20R,Q235,16Mn, 16MnR,1Cr5Mo,
12CrMo, 12CrMoG, 12Cr1Mo
Standard Specification ASTM,JIS,BS,DIN,UNI etc.
Connection Welding
Shape Equal
Technics Casting
Qualification ISO9001, API,CE
Equipment Pushing Machine,Beveling Machine,Sand Blasting Machine
Thickness Sch10-Sch160 XXS
Size Seamless 1/2" To 24" Welded 24" To 72"
Surface of Finish Antirust Oil,Hot Galvanized and Polish
Pressure Sch5--Sch160,XXS
Standard ASME,ANSI B16.9; DIN2605,2615,2616,2617,JIS B2311 ,2312,2313; EN 10253-1 ,EN 10253-2
The third party inspection BV, SGS, LOIYD, TUV, and other party alloyed by clients.
Remark Also can supply IBR fittings and Specialized NACE & HIC Fittings
Marking Registered logo,Heat Number,Steel Grade,Standard,Size
MinimumOrder Quantity 1pcs
Supply Ability 800Tons per month
Price Depending on quantity
Payment Terms T/T or Western Union or LC
Supply Ability 3,0000pcs per month
Delivery Time 7-15 days depending on quantity
Packing PLY-wooden case or pallet or as for clients' requirements
Application Petroleum, chemical, machinery, electric power, shipbuilding, papermaking,


1. 20 + years of production experience at your service.
2. The fastest delivery
3. The lowest price
4. Most comprehensive standards and materials for your choice.
5. 100% export.
6. Our products EXPORT to Africa, Oceania, mid east, eastern Asia, Western Europe etc.

Special design available as the requirement of customer

2:Butt Welding Fittings in the following forms
 Elbows 45o and 90o – long radius is standard; short radius is also available
 Return bends 180o – long radius is standard; short radius is also available
 Reducers – concentric and eccentric
 Tees – equal and reducing
 Caps
 Stub ends – Type B, to MSS SP-43
Butt welding fittings can be supplied in either seamless or welded construction and are covered by
specification ASTM A403M (or ASTM A815M for Duplex grades) and ASME B16.9
3:Product Show
Durable Stainless Steel Fittings Nickel Copper Alloy 500 Excellent Corrosion Resistance 0
