Cold Work Tool Alloy Steel Seamless Pipes NC6 NC10 NC11 X210Cr12 1.2080 High Strength

Place of Origin China/Japan
Brand Name BEST
Certification API, CE, PED, ISO
Model Number 1/2''-48''
Minimum Order Quantity Negotiation
Price Negotiation
Packaging Details Pipes May be furnished bard or coated and with capped ends
Delivery Time 5-8 working days
Payment Terms L/C /TT
Supply Ability 10000ton/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Coated Black Painting , Caps Standard API / GB / DIN/ ASTM /EN/NFA/BS/UNI/ISO/GOST/JIS /GB5310
Certificate EN10204 -3.1 /3.2 Specific Qualification TUV:AD WO-TRD100 / PED97/23/EC /IBR
Identification And Marking All Products Are Identified In Accordance With The Material Specification And/ Or In Accordance With P O Requirements (to Be Agreed). OD Tolerance ±1% Or ±0.5mm , Whichever Is The Greater
High Light

alloy steel pipe

,

alloy steel seamless tubes

Leave a Message
Product Description

COLD-WORK TOOL STEEL



Used in the production of tool kits for punching and cutting tools for sheet metal, thread rolling jaws of cold, dies and punches to the extrusion blade for cutting wood and metal, pneumatic chisels, punches, cutters, dies for cold, form into bending, straightening rolls, etc.

Technical specifications:

PN EN Werkstoff nr AISI
NC6
NC10
NC11 X210Cr12 1.2080 D3
NC11LV X153CrMoV12 1.2379 D2
NMV 90MnCrV8 1.2842 O2
NZ3 60WCrV8 1.2550 S1



Carbon steel is used in the production of medium-bearing, such as axles, crankshafts, eccentric, and toothed, spindles, rollers, pump rotors, pistons, levers, wedges, rods, screws, rings, etc.

Non-alloy steel arise from the construction, welded, riveted and joined with screws operating at ambient temperature.

Cutting steel is used for machining on automatic and high-speed machine tools for threading.

Technical specifications:

PN EN Werkstoff nr AISI
20 C22 1.1151 1020
45 C45 1.1191 1042
55 C55 1.1203 1055
St5 S275J2 1.0145
R35 E235N 1.0308 1010
P355 P355GH 1.0473
ST3S S235JR 1.0038
18G2A S355J2G3 1.0045
A1OX 11SMn30/9SMn28 1.0715
  11SMnPb28 1.0718





Appropriate for the production of heavily loaded, exposed to shocks, torsion or vibration, such as shafts, crankshafts, rotors, blades of steam turbines, spindles, levers, axles of vehicles, connecting rods, shafts, pumps and presses, parts control, rings.

Technical specifications:


PN EN Werkstoff nr AISI
36HNM 36CrNiMo4 1.6511 4340
34HNM 34CrNiMo6 1.6582 4337
40H 41Cr4 1.7035 5140
25HM 25CrMo4 1.7218 4130
35HGS
40HM 42CrMo4 1.7225 4140



Suitable for machine parts with high strength core with very high surface hardness.

Technical specifications:


PN EN Werkstoff nr AISI
40HMF 40CrMoV4-6 1.7711
38HMJ 41CrAlMo7-10 1.8509 D6


Practical for the production of machine parts with required surface layer with high hardness and ductile core, such as gears, screws, shafts, sleeves, large size – parts to be very high pressures and loads.

Technical specifications:

PN EN Werkstoff nr AISI
16HG 16MnCr5 1.7131 5115
15HN 17CrNi6-6 1.5918
17HNM 18CrNiMo7-6 1.6587 4820
18GHT
20HG 20MnCr5 1.7147 5120
18H2N2 19CrNi8 1.2722


Name : WB36 (T36/P36, 15NiCuMoNb5-6-4) HOT ROLLED TUBES FOR HIGH TEMPERATURE AND PRESSURE APPLICATIONS​


Definition :

WB36 is a bainitic Ni-Cu-Mo steel micro-alloyed with niobium. It is also known as 15NiCuMoNb5-6-4 according to EN 10216-2 and VdTÜV377/2, T36 according to ASTM A 213 and P36 according to ASTM A 335.

Application:

This grade is mainly used in high-pressure, medium-temperature feedwater lines (close to 400 °C).

Challenges :

WB36 exhibits excellent high-strength properties up to 450 °C. The reduced weight of the feedwater piping components compared with conventional carbon steel allows improved resistance to thermal fatigue and very good heat transfer.

Key advantages of Best Pipeline include:

  • Production and delivery of our own steel products, especially boiler pipes made of X10CrMoVNb9-1 and X10CrWMoVNb9-2 grades as well as other materials designed for high-temperature service
  • Design of the boiler parts, pipeline elements, Y-fittings and T-fittings
  • Prefabrication and assembly of boiler and industrial piping
  • Services:
    • technical consultations on preparing delivery, production and assembly contracts/agreements in order to provide a constant control/inspection over fulfilling the requirements listed in the “Delivery Technical Conditions” and “Construction and Commissioning Requirements”.
    • inspection and control over technological processes as per contracts/agreements in order to assure their realisation within the agreed time, cost reduction and quality of the final product
    • examination and testing followed by the final acceptance performed by the Notified Bodies. Additional creep tests of materials designed for the high-temperature service
    • free of charge preliminary examinations of pipelines in service using a portable SFM to determine their life assessment and evaluate the necessity of repairs, modernisation or further investments.



1. steel pipes for pressure equipment. Unalloyed steel pipes with specified room temperature properties – manufactured in accordance with PN-EN 10216-1 standard:

P195TR1, P195TR2, P235TR1, P235TR2, P265TR1, P265TR2


2. pipes for pressure purposes in elevated temperatures – boiler pipes – manufactured in accordance with PN-EN 10216-2 standard: P195GH, P235GH, P265GH, 16Mo3, 14MoV6-3, 13CrMo4-5, 10CrMo9-10, X10CrMoVNb9-1, X10CrWMoVNb9-2
3. pipes for pressure purposes made of fine-grained steel – manufactured in accordance with PN-EN 10216-3 standard:

Standard quality: P355N, P460N, P620Q, P690Q;

  • For application at elevated temperatures: P275NH, P355NH, P460HN, P620QH, P690QH;
  • For application at low temperatures: P275NL1, P355NL1, P460NL1, P620QL, P690QL1;
  • For application at special low temperatures: P275NL2, P355NL2, P460NL2, P690QL2
4. pipes for pressure purposes made of alloyed and unalloyed steel for application at low temperatures – manufactured in accordance with PN-EN 10216-4 standard:

P215NL, P255QL, P265NL, 26CrMo4-2, 11MnNi5-3, 13MnNi6-3, 12Ni14, X12Ni5, X10Ni9

5. seamless steel pipes for pressure purposes – pipes made of corrosion-resistant steel – manufactured in accordance with PN-EN 10216-5 standard:

X2CrNi18-9, X2CrNi19-11, X5CrNi18-10, X6CrNiTi18-10, X6CrNiNb18-10, X2CrNiMo17-12-2, X5CrNiMo17-12-2, X1CrNiMoN25-22-2, X6CrNiMoTi17-12-2, X2CrNiMo18-14-3, X1NiCrMoCu25-20-5, X2CrNiMoN22-5-3, X15CrNiSi25-20


6. steel pipes for transportation of combustible fluids – pipes of requirement class A – manufactured in accordance with PN-EN 10208-1 standard:

L210GA, L235GA, L245GA, L290GA, L360GA


7. steel pipes for transportation of combustible fluids – pipes of requirement class B – manufactured in accordance with PN-EN 10208-2 standard:

L210GA, L235GA, L245GA, L290GA, L360GA
