2.31-50mm WT Welded LSAW Incoloy Pipe Solid Structure According To API 2B Standards

  • 2.31-50mm WT Welded LSAW Incoloy Pipe Solid Structure According To API 2B Standards
  • 2.31-50mm WT Welded LSAW Incoloy Pipe Solid Structure According To API 2B Standards
  • 2.31-50mm WT Welded LSAW Incoloy Pipe Solid Structure According To API 2B Standards
  • 2.31-50mm WT Welded LSAW Incoloy Pipe Solid Structure According To API 2B Standards
  • 2.31-50mm WT Welded LSAW Incoloy Pipe Solid Structure According To API 2B Standards
  • 2.31-50mm WT Welded LSAW Incoloy Pipe Solid Structure According To API 2B Standards
Place of Origin China
Brand Name Best
Certification API /CE / ISO /TUV
Model Number 1/2'' -48''
Minimum Order Quantity 1 TONS
Price 450 USD/TON
Packaging Details 1) In bundle with strip; 2) First packing by plastic bag then strip; Details packing please see the picture in the detial description.
Delivery Time Shipped in 25 days after payment
Payment Terms L/C, T/T
Supply Ability 100000 Ton/Year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Standard API 5L ERW Technique SAW/UOE
Finish Bared Keyword LSAW STEEL PIPE
High Light

spiral welded steel pipe

,

lsaw steel tube
Leave a Message
Product Description
LSAW,Seamless /ERW steel line pipe IN API for oil,gas and water.

Standard: API 5L PSL1 OR PSL2/ASTM A106/A53

Size:
OD:3/8”-56” (17.1-1422mm)
WT:2.31-50mm
MILL TEST CERTIFICATE IN EN 10204/3.1B

1,Chemical composition in %


TYPESteel gradeC .SiMn .PS
API 5L PSL1B≤0.28-≤1.20≤0.03≤0.03
API 5L PSL1X42≤0.28-≤1.3≤0.03≤0.03
API 5L PSL1X46≤0.28-≤1.4≤0.03≤0.03
API 5L PSL1X52≤0.28-≤1.4≤0.03≤0.03
API 5L PSL1X56≤0.28-≤1.4≤0.03≤0.03
API 5L PSL1X60≤0.28-≤1.4≤0.03≤0.03
API 5L PSL1X70≤0.28-≤1.4≤0.03≤0.03











Mechanical Properties


TYPESteel grade

Tensile strength
(Mpa)

Yield strength
(Mpa)

Elongation
API 5L PSL1B≥415≥245As per API 5L
API 5L PSL1X42≥415≥290As per API 5L
API 5L PSL1X46≥435≥320As per API 5L
API 5L PSL1X52≥460≥360As per API 5L
API 5L PSL1X56≥490≥390As per API 5L
API 5L PSL1X60≥520≥415As per API 5L
API 5L PSL1X70≥565≥483As per API 5L



2,Chemical composition in %


LevelSteel gradeC .SiMn .PS
PSL2B≤0.24-≤1.20≤0.03≤0.03
PSL2X42≤0.24-≤1.3≤0.03≤0.03
PSL2X46≤0.24-≤1.4≤0.03≤0.03
PSL2X52≤0.24-≤1.4≤0.03≤0.03
PSL2X56≤0.24-≤1.4≤0.03≤0.03
PSL2X60≤0.24-≤1.4≤0.03≤0.03
PSL2X65≤0.24-≤1.4≤0.03≤0.03
PSL2X70≤0.24-≤1.4≤0.03≤0.03













Mechanical Properties


LevelSteel grade

Tensile strength
(Mpa)

Yield strength
(Mpa)

Elongation
PSL2B415-760245-450As per API 5L
PSL2X42415-760290-495As per API 5L
PSL2X46435-760320-525As per API 5L
PSL2X52460-760360-530As per API 5L
PSL2X56490-760390-545As per API 5L
PSL2X60520-760415-565As per API 5L
PSL2X65535-760450-600As per API 5L
PSL2X70565-758483-621

As per API 5L
