UNS S31803 Duplex 2205 Seamless Stainless Steel Tubing High Heat Conductivity
| Place of Origin | China |
|---|---|
| Brand Name | Best |
| Certification | API/CE/ ISO / |
| Model Number | 1/4' -48'' |
| Minimum Order Quantity | 1 Pcs |
| Price | 1200 usd/ton |
| Packaging Details | Regular shipping packaging or depends on customer's requirement |
| Delivery Time | 5-8 working days |
| Supply Ability | 10000 Ton/Moth |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Standard | ASTM A790 | Grade | S31803 |
|---|---|---|---|
| Type | Seamless Duplex Stainless Steel Pipes | Place Of Origin | China |
| Material | 2205/2507 | Production Year | 2018 |
| High Light | 2205 duplex stainless steel tubing,duplex steel pipes |
||
Product Description
Production Name : Super Duplex Stainless Steel Pipes Size : 14'' We are Super Duplex Factory Specialized in Duplex 2250 /2507
Product Description
UNS S31803 and UNS S32205 are commonly referred to as Duplex 2205® material, whose “Duplex” name is derived from the mixed microstructure which contains about equal portions of ferrite and austenite. Developed more than 70 years ago in Sweden precisely for the sulfite paper industry where the Duplex’s were used to combat corrosion problems caused by chloride-bearing cooling waters and other aggressive chemical products. Since then there have been advancements in the composition such as the deliberate addition of nitrogen as an alloying agent, which afterwards quickly made Duplex the “workhorse” of stainless steels.
Duplex S31803 and Super Duplex S32750 Performance
Duplex S31803, also known as stainless steel grade 2205, is a standardized formulation that conforms to UNS specification regulations. Its temperature range is typically listed as -50° to 300° C (-58° to 572° F); outside of this range, its performance characteristics degrade. Specifically, duplex S31803's micro-components experience precipitation with prolonged exposure to high temperatures, and ductility suffers with immersion in extremely cold environments.
Its general capabilities include:
- Excellent oxidation resistance
- Outstanding performance in marine/sea water environments
- Low thermal expansion coefficients
- High heat conductivity
Chemical Composition Table
UNS: S31803
| C | Mn | P | S | Si | Cr | Ni | N | Mo | |
|---|---|---|---|---|---|---|---|---|---|
| Min | 21.0 | 4.5 | 0.08 | 2.5 | |||||
| Max | 0.030 | 2 | 0.030 | 0.020 | 1.00 | 23.0 | 6.5 | 0.20 | 3.5 |
UNS: S32750
| C | Mn | P | S | Si | Cr | Ni | N | Mo | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|
| Min | 24.0 | 6.0 | 0.24 | 3.0 | ||||||
| Max | 0.030 | 1.20 | 0.035 | 0.020 | 0.80 | 26.0 | 8.0 | 0.32 | 5.0 | 0.50 |
The physical properties of grade 2205 stainless steels are tabulated below. Grade S31803 has similar physical properties to that of S32205.
Physical properties of 2205 grade stainless steels
| Grade | Density (kg/m3) |
Elastic Modulus (GPa) |
Mean Co-eff of Thermal expansion (μm/m/°C) |
Thermal Conductivity (W/m.K) |
Specific Heat 0-100°C ( J/kg.K) |
Electrical Resistivity (nΩ.m) |
|||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| UNS S31803 | 782 | 190 | 13.7 | 14.2 | - | 19 | - | 418 | 850 |
