SS 347H Electric Resistance Welded Steel Pipe , Long Seamless Carbon Steel Pipe
Product Details
stainless steel seamless pipe
,seamless stainless steel tubing
Product Name : Stainless Steel 347H Tubes(UNS S34709) is the higher carbon composition form of Alloy 347 and demonstrates improved high
What is 347 H?
Stainless Steel 347H Welded Pipes has to be water quenched and annealed to obtain maximum hardness. However forging, upsetting and other hot work processes can be performed at 1149 to 1232 Degree C (2100 to 2250 Degree F). SS 347H Welded Tubes has superior general corrosion resistance over Type 321 due to stabilization with columbium. Due unique properties, Stainless Steel 347H Tubing is used in a variety of application in many of today’s critical industries: Boiler tubes and casings, Oil and gas refinery piping, Radiant superheaters, High-pressure steam pipes, Heat exchanger tubes, Cabin heaters, Heavy wall-welded equipment, Aircraft exhaust stacks and collector rings, and more.
Stainlesss Steel 347H Pipes & Tubes Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN |
| SS 347H | 1.4961 | S34709 | – | – | – | – | – |
TP 347H Stainless Steel Pipes & Tubes Chemical Composition :
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Co + Ta | |
| 347H | Min | 0.04 | – | – | – | – | 17.0 | – | 9.00 | 8xC min |
| max | 0.10 | 2.00 | 1.00 | 0.045 | 0.030 | 19.0 | – | 13.00 | 1.00max |
ASTM A312 / A213 SS TP 347H Pipes & Tubing Mechanical properties:
| Density | 8.0 g/cm3 |
| Melting Point | 1454 °C (2650 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
ASTM A312 / A213 SS TP 347H Pipes Pictures :
-
