UNS S31254 Stainless Steel Fittings Austenitic S31803 20 Sch 140 Elbow
Product Details
stainless steel 316 pipe fittings
,stainless steel pipe flange
Product Name : 20” sch. 140 Elbow according to UNS S31254 (SMO) Ferritic / Austenitic (Duplex / Super Duplex) S31803 S32750 S32760
1.Product information of steel elbow
Seamless Butt Weld Pipe Fittings Specification :
Standards : ASME / ANSI - B 16.9, ASTM A403 - ASME SA403, ASME B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
Dimensions : ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313
Size : 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Thickness : SCH: 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS, Custom Thickness.
Other Materials : Monel, Nickel, Inconel, Hastelloy, Copper, Brass, Bronze, Titanium, Tantalum, Bismuth, Aluminium, Zinc, Lead, etc.
Types : Seamless, Fabricated
Seamless Butt Weld Pipe Fittings Material & Grades :
Stainless Steel Seamless Butt weld Pipe Fittings : ASTM A403 WP 304/ 304L/ 304H/ 316/ 316L/ 317/ 317L/ 321/ 310/ 347/ 904L/2205 Duplex Fittings
Alloy Steel Seamless Butt weld Pipe Fittings : ASTM A234 WP1/ WP5/ WP9/ WP11/ WP22/ WP91
Carbon Steel Seamless Butt weld Pipe Fittings : ASTM A234 WPB / A420 WPL3/ A420 WPL6/ MSS-SP-75 WPHY 42/46/52/56/60/65/70
Copper Nickel Seamless Buttweld Pipe Fittings : CuNi10Fe1Mn, CuNi30Mn1Fe
| Variations |
|
| Standards |
ASTM A403 - ASME SA403 - 'Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings' ASME B16.9 - 'Factory-Made Wrought Buttwelding Fittings'' MSS SP-43 - 'Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications' |
| Dimensions |
Outside diameter : 1/2" to 24" Thickness : SCH 5S, 10S, 40S (STD), 80S (XS), 160, XXS |
2:Product Show
-
