Product Details
Material X1CrNiMoCuN25-20-7 Steel Number 1.4529
Type Heat Resistant Stainless Steel Pipe Standard EN 10216-5
High Light

Heat Resistant Stainless Steel Pipe EN 10216-5

,

1.4529 Steel Pipe
Leave a Message
Product Description
Grade :X1NiCrMoCuN25-20-7
Number:1.4529
Classification:Austenitic stainless steel - special grade
Density:8.1 g/cm ³
Standard:
EN 10088-2: 2005 Stainless steels. Technical delivery conditions for sheet/plate and strip of corrosion resisting steels for general purposes
EN 10088-3: 2005 Stainless steels. Technical delivery conditions for semi-finished products, bars, rods, wire, sections and bright products of corrosion resisting steels for general purposes
EN 10028-7: 2007 Flat products made of steels for pressure purposes. Stainless steels
EN 10216-5: 2014 Seamless steel tubes for pressure purposes. Technical delivery conditions. Stainless steel tubes
EN 10217-7: 2005 Welded steel tubes for pressure purposes. Stainless steel tubes
EN 10253-3: 2008 Butt-welding pipe fittings. Wrought austenitic and austenitic-ferritic (duplex) stainless steels without specific inspection requirements
EN 10253-4: 2008 Butt-welding pipe fittings. Wrought austenitic and austenitic-ferritic (duplex) stainless steels with specific inspection requirements
EN 10272: 2007 Stainless steel bars for pressure purposes
EN 10250-4: 2000 Open steel die forgings for general engineering purposes. Stainless steels
EN 10297-2: 2005 Seamless circular steel tubes for mechanical and general engineering purposes. Stainless steel. Technical delivery conditions
EN 10088-1: 2005 Stainless steels. List of stainless steels
EN 10088-5: 2009 Stainless steels. Technical delivery conditions for bars, rods, wire, sections and bright products of corrosion resisting steels for construction purposes
EN 10088-4: 2009 Stainless steels. Technical delivery conditions for sheet/plate and strip of corrosion resisting steels for construction purposes



Chemical composition % of steel X1NiCrMoCuN25-20-7 (1.4529): EN 10088-2-2005
Elements not listed in this table shall not be intentionally added to the steel without the agreement of the purchaser except for finishing the cast.
CSiMnNiPSCrMoNCu
max 0.02max 0.5max 124 - 26max 0.03max 0.0119 - 216 - 70.15 - 0.250.5 - 1.5

Mechanical properties of steel X1NiCrMoCuN25-20-7 (1.4529)

Rm - Tensile strength (MPa) (+A)650-850
Rm - Tensile strength (MPa) (+AT)600-800

Rp0.2 0.2% proof strength (MPa) (+A)300-340
Rp0.2 0.2% proof strength (MPa) (+AT)270-300

KV - Impact energy (J) transverse, (+A)+20°
60		-196°
60
KV - Impact energy (J) longitud., (+A)+20°
100
KV - Impact energy (J) longitud., (+AT)+20°
100-120
KV - Impact energy (J) transverse, (+AT)+20°
60-90		-196°
60

A - Min. elongation at fracture (%) (+A)35-40
A - Min. elongation at fracture (%) longitud., (+AT)35
A - Min. elongation at fracture (%) transverse, (+AT)30

Brinell hardness (HB): (+A)250
Brinell hardness (HB): (+AT)220

Properties of steel X1NiCrMoCuN25-20-7 (1.4529)
Resistance to intergranular corrosion: in the delivery condition - yes; in the sensitized condition - yes
Steel shal not be applied at a metal temperature lower than -196 ° C

Equivalent grades of steel X1NiCrMoCuN25-20-7 (1.4529)
Warning! Only for reference
EU
EN		USA
-
X1NiCrMoCuN25-20-7
N08926
NO8367
