Product Details
Material C40 Steel Number 1.0511
Type Seamless Fittings Standard Asme B16.9
Leave a Message
Product Description

C40 butt welding fittings 1.0511 Seamless Fittings ASME B16.9 Seamless Steel Fittings



BUTT-WELDING PIPE FITTINGS DETAILS
MATERIAL
Carbon Steel :
ASTM, A234WPB, A234WPC, A420WPL6 ,Q235,10#, A3, Q235A, 20G,16Mn,
DIN St37, St45.8, St52.4,St.35.8,St.35.8.
Stainless Steel:
1Cr18Ni9Ti 0Cr18Ni9 00Cr19Ni10 0Cr17Ni12Mo2Ti
00Cr17Ni14Mo2 304 304L 316 316L
Alloy Steel:
16Mn Cr5Mo 12Cr1MoV 10CrMo910 15CrMo 12Cr2Mo1,
A335P22 St45.8, ASTM A860 WPHY X42 X52 X60 X70
STANDARD
ASTM / JIS / DIN / BS / GB/GOST
MODEL
1.Tee(Straight and Reducing) 2.180 DEG Return
3.Elbow (45/90/180 DEG) 4.Cap
5. Reducer(Concentric and Eccentric)
TYPE
Seam Or Seamless
ELBOW DEGREE
45 degree, 90 degree, 180 degree
SURFACE
Black Paint, Anti Rust Oil, Hot-Dipped Galvanize
WALL THICKNESS
SCH5S,SCH10S,SCH10,SCH20,SCH30,SCH40,STD,XS,SCH60,
SCH80,SCH100,SCH120,SCH140,SCH160,XXS,2MM
SIZE
1/2"-48"(Dn15-Dn1200)
CONNECTION
Welding
SHAPE
Equal, Reducing
CERTIFICATE
ISO9001
APPLICATION
Petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, etc
RELATED PRODUCTS
1. Carbon steel nipples and sockets
2. Flanges
3. Malleable iron pipe fittings
4. Pipes
5. High-pressure fittings
6. Valves
7. P.T.F.E .thread seal tape
8. Brass fittings
9. Ductile iron pipe fittings
10. Copper fittings
11. Sanitary fittings, etc,.
12. Grooved fittings
Customers’ drawings or designs are available.
PACKAGE
1> 1/2" - 2" in cartons.
2>Above 2" in wooden cases.
Big size is workable by pallets.
DELIVERY DETAILS
According to the quantities and specifications of each order.
Normal delivery time is from 30 to 45 days after receiving the deposit.





C40 butt welding fittings 1.0511 Seamless Fittings ASME B16.9 Seamless Steel Fittings 0

Grade : C40
Number: 1.0511
Classification: Non-alloy quality steel
Standard:
EN 10277-2: 2008 Bright steel products. Technical delivery conditions. Steels for general engineering purposes
EN 10083-2: 2006 Steels for quenching and tempering. Technical delivery conditions for non alloy steels
EN 10250-2: 2000 Open steel die forgings for general engineering purposes. Non-alloy quality and special steels





Chemical composition % of steel C40 (1.0511): EN 10277-2-2008
Cr + Mo + Ni = max 0.63
C Si Mn Ni P S Cr Mo
0.37 - 0.44 max 0.4 0.5 - 0.8 max 0.4 max 0.045 max 0.045 max 0.4 max 0.1


Mechanical properties of steel C40 (1.0511)

Nominal thickness (mm): to 16 16 - 100 100 - 250
Rm - Tensile strength (MPa) (+N) 580 550 530
Nominal thickness (mm): 5 - 10 10 - 16 16 - 40 40 - 63 63 - 100
Rm - Tensile strength (MPa) (+C) 700-1000 650-980 620-920 590-840 550-820

Nominal thickness(mm): to 16 16 - 100 100 - 250
Re - Upper yield strength or
Rp0.2 - 0.2% proof strength (MPa) (+N)		 320 290 260
Nominal thickness(mm): 5 - 10 10 - 16 16 - 40 40 - 63 63 - 100
Rp0.2 0.2% proof strength (MPa) (+C) 540 460 365 330 290

Nominal thickness (mm): 5 - 10 10 - 16 16 - 40 40 - 63 63 - 100
A - Min. elongation at fracture (%) (+C) 6 7 8 9 9

Nominal thickness (mm): to 16 16 - 100 100 - 250
A - Min. elongation Lo = 5,65 √ So (%) (+N) 16 17 17

Brinell hardness (HBW): (+SH) 163 - 211


Properties of steel C40 (1.0511)
Weldability: Due to the medium-high carbon content it can be welded with some precautions.
Hardenability: Low hardenability; it shows intermediate features between those of steels with medium and those of steels with high carbon content; therefore it is not easy to obtain the required features by quenching in oil and the quenching in water can result in cracking.



Equivalent grades of steel C40 (1.0511)

EU
EN		 USA
-		 Germany
DIN,WNr		 Japan
JIS		 France
AFNOR		 England
BS		 Italy
UNI		 China
GB		 Poland
PN		 Czechia
CSN		 Russia
GOST		 Inter
ISO
C40
1038
1040
1.0511
C40
Ck40
S40C
AF60C40
AF60C45
XC42HI
070M40
080M40
En8
C40
40
40
12041
40
C40
C40E4
