P265NL 1.0453 Steel WN Flange EN1092-1 Long Neck Flanges
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | P265nl | Steel Number | 1.0453 |
|---|---|---|---|
| Standard | EN1092-1 Type 01 | Face | RF , FF |
| High Light | 1.0453 Steel WN Flange,Long Neck WN Flange,EN1092-1 Long Neck Flanges |
||
Product Description
P265NL Steel flanges ( 1.0453 ) wn flange EN1092-1 LONG NECK FLANGES
| Grade : | P265NL | ||||
| Number: | 1.0453 | ||||
| Classification: | Non-alloy low temperature quality steel | ||||
| Standard: |
|
||||
| Equivalent grades: | No information |
Chemical composition % of steel P265NL (1.0453): EN 10216-4-2014
| C | Si | Mn | Ni | P | S | Cr | Mo | V | Nb | Ti | Al | Cu |
| max 0.2 | max 0.4 | 0.6 - 1.4 | max 0.3 | max 0.025 | max 0.01 | max 0.3 | max 0.08 | max 0.02 | max 0.01 | max 0.04 | max 0.02 | max 0.3 |
Mechanical properties of steel P265NL (1.0453)
| Rm - Tensile strength (MPa) (+N) | 410-570 |
| Rp0.2 0.2% proof strength (MPa) (+N) | 265 |
| KV - Impact energy (J) transverse, | -40° 27 |
-20° 30 |
+20° 35 |
| KV - Impact energy (J) longitud., | -40° 40 |
-20° 45 |
+20° 50 |
| A - Min. elongation at fracture (%) longitud., (+N) | 24 |
| A - Min. elongation at fracture (%) transverse, (+N) | 22 |
