What is the availability of the X10CrMoVNb9-1 Alloy seamless Pipes pipe

Brand Name Global
Model Number 4inch
Minimum Order Quantity 1 tons
Packaging Details Standard exported package
Delivery Time 5-8 working days
Payment Terms L/C, D/A, D/P, T/T, MoneyGram

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Leave a Message
Product Description

What is the availability of the X10CrMoVNb9-1 Alloy seamless Pipes and tubes





Alloy Boiler Steel : X10CrMoVNb9-1



X10CrMoVNb9-1 :  DESIGNATIONS​



ASTM / ASME plate  :  A/SA 387 gr.91

ASTM / ASME bar :  A/SA 182 F91

ASTM / ASME pipe :  A/SA 335 P91

W.stoff no:    1.4903





X10CrMoVNb9-1  APPLICATION:  Martensitic, high temperature steel. Main fields are for example powerplants, pressure valves and oil-, gas-, chemical industries. Excellent resistance to high working temperatures up to appr. 650°C



X10CrMoVNb9-1  DELIVERY PROGRAMME



Our plates are always according to EN 1.4903/X10CrMoVNB9-1 / ASTM A 387 / ASME SA 387 with ultrasonic-test acc. to both EN 10160 S2/E3 and ASTM A578 level C. The material is tempered at 770°C





DIMENSION:  Plate : 6-60mm

Round Bar : 20-700mm

Forging : Yes

Pipe : Yes



X10CrMoVNb9-1   CHEMICAL COMPOSITION  :



Al        min. 0,040

C         0,08 - 0,12

Cr        8,00 - 9,50

Cu       max. 0,30

Mn        0,30 - 0,60

Mo        0,85 - 1,05

N          0,030 - 0,070

Nb          0,06 - 0,10

Ni          max. 0,30

P           max. 0,020

S           max. 0,005



X10CrMoVNb9-1 MECHANICAL PROPERTIES :



Yield :   min. 435 N/mm²

Tensile :   580 - 760 N/mm²



KV :  +20°C / 40J
