300LBS Pressure Large Diameter Lap Joint Flange in 304L Forged Steel

Basic Properties
Place of Origin: China
Brand Name: Best
Certification: API/CE/ISO/PED
Model Number: 1/2''-48''
Trading Properties
Minimum Order Quantity: 1 Pcs
Price: 1 usd/pcs
Payment Terms: L/C/ TT
Supply Ability: 100000 Ton/Year
Tags

stainless steel flanges

carbon steel forged flanges

weld neck flanges
Product Summary
300LBS pressure lap joint flange made from forged 304L steel. High-strength material ensures durability and efficiency for industrial piping systems. Complies with DIN 2566 and TS 813/3 standards.

Product Details

Highlight:

weld neck flanges

,

stainless steel flanges
Name: Lap Joint Flange
Pressure: 300LBS
Material: 304L
Place Of Origin: China
Model Number: RC-BL Flange
Type: Forged Steel Flanges
Product Description
300LBS Pressure Large Diameter Steel Flanges DIN 2566 TS 813/3 High Strength Material
Product Overview

Product Name: Lap Joint Flange
Pressure Rating: 300 lbs
Material: 304L Forged Steel Flanges

A flange is defined as a plate-type device, typically round, that is attached to the end of a pipe, fitting, valve, or other object to facilitate the assembly and disassembly of a piping system.

Flanges are manufactured in various materials to match the pipe and fitting materials. While some flanges are made of cast iron, the majority are forged carbon steel for enhanced strength and durability.

Flange Types
  • Weld Neck Flanges
  • Slip-On Flanges
  • Lap Joint Flanges
  • Threaded Flanges
  • Socket Weld Flanges
  • Blind Flanges
Forged Steel Flange Specifications

Size Range: ½" TO 54"

Pressure Ratings: 150#, 300#, 600#, 900#, 1500#, 2500#

Standards: ASME B 16.5, ASME B 16.47, API 6A

Types: SORF, WNRF, SWRF, BLRF, Threaded, etc.

Special Variants: Spacers, Spectacle Blinds, Drip Rings, RTJ, Tongue, Groove, Orifice, etc.

Available Materials

Carbon Steel: A-105, A-350 LF2 [NACE + HIC] etc.

Alloy Steel: F-5, F-9, F-11, F-22, F-91 etc.

Stainless Steel: SS 304, SS 304L, SS316, SS 316L, SS 316Ti, SS 321, SS 347, SS 304H, 317L, 347H, etc.

Duplex SS: F-51, F-55

High Strength Steel: A694 Gr 52, 60, 65, 70, AISI 4130, 4140

Nickel Alloys: Monel 400, Inconel 625, Inconel 825, Alloy 20, etc.

150lb Flange Dimensions
Nominal Bore Pipe OD A Flange dia. B Raised Face dia. D Flange Thickness T Welding Neck Slip-on/Screwed/Socket-weld Bolt PCD No. of Bolts Bolt Hole dia.
1521.488.934.911.147.615.960.3415.9
2027.098.442.912.752.415.969.8415.9
2534.1107.950.814.355.617.579.4415.9
3242.9117.563.515.957.120.688.9415.9
4048.4127.073.017.561.922.298.4415.9
5060.3152.492.119.063.525.4120.6419.0
6573.0177.8104.822.269.828.6139.7419.0
8088.9190.5127.023.869.830.2152.4419.0
90101.6215.9139.723.871.431.7177.8819.0
100114.3228.6157.223.876.233.3190.5819.0
125141.3254.0185.723.888.936.5215.9822.2
150165.1279.4215.925.488.939.7241.3822.2
150168.3279.4215.925.488.939.7241.3822.2
200219.1342.9269.928.6101.644.4298.4822.2
250273.1406.4323.830.2101.649.2361.91225.4
300323.9482.6381.031.7114.355.6431.81225.4
350355.6533.4412.734.9127.057.1476.21228.6
400406.4596.9469.936.5127.063.5539.71628.6
450457.2635.0533.439.7139.768.3577.81631.7
