Heavy Wall LSAW Steel Pipe with Bared Finish Manufactured by Press Bending Machine
Basic Properties
Place of Origin:
China
Brand Name:
Best
Certification:
API /CE / ISO /TUV
Model Number:
1/2'' -48''
Trading Properties
Minimum Order Quantity:
1 TONS
Price:
450 USD/TON
Payment Terms:
L/C,T/T
Supply Ability:
100000 Ton/Year
Product Summary
LSAW steel pipe manufactured with SAW/UOE technique, bared finish. Compliant with API 5L PSL1/PSL2 standards for oil, gas, and water applications. Available in OD 3/8"-56" and WT 2.31-50mm with EN 10204/3.1B mill certificates.
Product Details
Highlight:
spiral welded steel pipe
,lsaw steel tube
Standard:
API 5L ERW
Technique:
SAW/UOE
Finish:
Bared
Keyword:
LSAW STEEL PIPE
Product Description
Longitudinal SAW Heavy Wall Steel Pipe Bared Finish By Press Bending Machine
LSAW, Seamless/ERW steel line pipe manufactured to API standards for oil, gas, and water applications.
Product Specifications
Standard: API 5L PSL1 or PSL2 / ASTM A106 / A53
Size Range:
- OD: 3/8" - 56" (17.1 - 1422mm)
- WT: 2.31 - 50mm
Certification: MILL TEST CERTIFICATE IN EN 10204/3.1B
Size Range:
- OD: 3/8" - 56" (17.1 - 1422mm)
- WT: 2.31 - 50mm
Certification: MILL TEST CERTIFICATE IN EN 10204/3.1B
Chemical Composition - PSL1 (%)
| Type | Steel Grade | C | Si | Mn | P | S |
|---|---|---|---|---|---|---|
| API 5L PSL1 | B | ≤0.28 | - | ≤1.20 | ≤0.03 | ≤0.03 |
| API 5L PSL1 | X42 | ≤0.28 | - | ≤1.3 | ≤0.03 | ≤0.03 |
| API 5L PSL1 | X46 | ≤0.28 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| API 5L PSL1 | X52 | ≤0.28 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| API 5L PSL1 | X56 | ≤0.28 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| API 5L PSL1 | X60 | ≤0.28 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| API 5L PSL1 | X70 | ≤0.28 | - | ≤1.4 | ≤0.03 | ≤0.03 |
Mechanical Properties - PSL1
| Type | Steel Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation |
|---|---|---|---|---|
| API 5L PSL1 | B | ≥415 | ≥245 | As per API 5L |
| API 5L PSL1 | X42 | ≥415 | ≥290 | As per API 5L |
| API 5L PSL1 | X46 | ≥435 | ≥320 | As per API 5L |
| API 5L PSL1 | X52 | ≥460 | ≥360 | As per API 5L |
| API 5L PSL1 | X56 | ≥490 | ≥390 | As per API 5L |
| API 5L PSL1 | X60 | ≥520 | ≥415 | As per API 5L |
| API 5L PSL1 | X70 | ≥565 | ≥483 | As per API 5L |
Chemical Composition - PSL2 (%)
| Level | Steel Grade | C | Si | Mn | P | S |
|---|---|---|---|---|---|---|
| PSL2 | B | ≤0.24 | - | ≤1.20 | ≤0.03 | ≤0.03 |
| PSL2 | X42 | ≤0.24 | - | ≤1.3 | ≤0.03 | ≤0.03 |
| PSL2 | X46 | ≤0.24 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| PSL2 | X52 | ≤0.24 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| PSL2 | X56 | ≤0.24 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| PSL2 | X60 | ≤0.24 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| PSL2 | X65 | ≤0.24 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| PSL2 | X70 | ≤0.24 | - | ≤1.4 | ≤0.03 | ≤0.03 |
Mechanical Properties - PSL2
| Level | Steel Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation |
|---|---|---|---|---|
| PSL2 | B | 415-760 | 245-450 | As per API 5L |
| PSL2 | X42 | 415-760 | 290-495 | As per API 5L |
| PSL2 | X46 | 435-760 | 320-525 | As per API 5L |
| PSL2 | X52 | 460-760 | 360-530 | As per API 5L |
| PSL2 | X56 | 490-760 | 390-545 | As per API 5L |
| PSL2 | X60 | 520-760 | 415-565 | As per API 5L |
| PSL2 | X65 | 535-760 | 450-600 | As per API 5L |
| PSL2 | X70 | 565-758 | 483-621 | As per API 5L |
Product Image
