1.2002 tool steel EN 10132-4: 2000 Cold rolled narrow steel strip for heat treatment 125Cr2 boiler steel pipes
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | 1.2002 Tool Steel | Standard | EN 10132-4: 2000 |
|---|---|---|---|
| Steel Material | 125Cr2 | Type | Tool Steel |
Product Description
| Grade : | 125Cr2 | |
| Number: | 1.2002 | |
| Classification: | Steel | |
| Standard: |
|
| C | Si | Mn | Ni | P | S | Cr | Mo |
| 1.2 - 1.3 | 0.15 - 0.35 | 0.25 - 0.4 | max 0.4 | max 0.025 | max 0.025 | 0.4 - 0.6 | max 0.1 |
Mechanical properties of steel 125Cr2 (1.2002)
| Nominal thickness (mm): | 0.3 - 3 |
| Rm - Tensile strength (MPa) (+A) | 750 |
| Nominal thickness (mm): | 0.3 - 3 |
| Rm - Tensile strength (MPa) (+QT) | 1300-2100 |
| Nominal thickness(mm): | 0.3 - 3 |
| Rp0.2 0.2% proof strength (MPa) (+A) | 590 |
| Nominal thickness (mm): | 0.3 - 3 |
| A - Min. elongation Lo = 80 mm (%) (+A) | 11 |
| Vickers hardness ( HV): (+A) | 235 |
| Vickers hardness ( HV): (+QT) | 405 - 630 |
