X6CrNiMoNb17-12-2 Heat Resistant Stainless Steel Pipe EN 10216-5 1.4580 Steel Pipes
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | X6CrNiMoNb17-12-2 | Steel Number | 1.4580 |
|---|---|---|---|
| Type | Heat Resistant Stainless Steel Pipe | Standard | Stainless Steel Pipe |
| High Light | ODM Heat Resistant Stainless Steel Pipe,OEM Heat Resistant Stainless Steel Pipe,1.4580 Steel Pipes |
||
Product Description
| Grade : | X6CrNiMoNb17-12-2 | |||||||
| Number: | 1.4580 | |||||||
| Classification: | Austenitic stainless steel - special grade | |||||||
| Density: | 8 g/cm ³ | |||||||
| Standard: |
|
| Nb = 10 * C to 1.0 Elements not listed in this table shall not be intentionally added to the steel without the agreement of the purchaser except for finishing the cast. |
| C | Si | Mn | Ni | P | S | Cr | Mo | Nb |
| max 0.08 | max 1 | max 2 | 10.5 - 13.5 | max 0.045 | max 0.015 | 16.5 - 18.5 | 2 - 2.5 | max 1 |
Mechanical properties of steel X6CrNiMoNb17-12-2 (1.4580)
| Rm - Tensile strength (MPa) (+A) | 510-740 |
| Rm - Tensile strength (MPa) (+AT) | 510-740 |
| Rp0.2 0.2% proof strength (MPa) (+A) | 215-220 |
| Rp0.2 0.2% proof strength (MPa) (+AT) | 215 |
| KV - Impact energy (J) transverse, (+A) | +20° 60 |
| KV - Impact energy (J) longitud., (+A) | +20° 100 |
| A - Min. elongation at fracture (%) (+A) | 35-40 |
| A - Min. elongation at fracture (%) longitud., (+AT) | 35 |
| A - Min. elongation at fracture (%) transverse, (+AT) | 30 |
| Brinell hardness (HB): (+A) | 230 |
Properties of steel X6CrNiMoNb17-12-2 (1.4580)
| Resistance to intergranular corrosion: in the delivery condition - yes; in the sensitized condition - yes Steel shal not be applied at a metal temperature lower than -196 ° C |
Equivalent grades of steel X6CrNiMoNb17-12-2 (1.4580)
| EU EN |
Russia GOST |
|
| X6CrNiMoNb17-12-2 |
|
