EN 10216-5 1.4563 Steel Pipes X1NiCrMoCu31-27-4 Heat Resistant Stainless Steel Pipe
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | X1NiCrMoCu31-27-4 | Standard | EN 10216-5 |
|---|---|---|---|
| Steel Number | 1.4563 | Type | Stainless Steel Pipes |
| High Light | 1.4563 Steel Pipes,Heat Resistant Stainless Steel Pipe |
||
Product Description
| Grade : | X1NiCrMo31-27-4 | ||
| Number: | 1.4563 | ||
| Classification: | Austenitic stainless steel - special grade | ||
| Standard: |
|
| According EN 10272-2007 steel 1.4563 named X1NiCrMoCu31-27-4 Elements not listed in this table shall not be intentionally added to the steel without the agreement of the purchaser except for finishing the cast. |
| C | Si | Mn | Ni | P | S | Cr | Mo | N | Cu |
| max 0.02 | max 0.7 | max 2 | 30 - 32 | max 0.03 | max 0.01 | 26 - 28 | 3 - 4 | max 0.11 | 0.7 - 1.5 |
Mechanical properties of steel X1NiCrMo31-27-4 (1.4563)
| Rm - Tensile strength (MPa) (+A) | 500-750 |
| Rp0.2 0.2% proof strength (MPa) (+A) | 220 |
| KV - Impact energy (J) transverse, (+A) | +20° 60 |
-196° 60 |
| KV - Impact energy (J) longitud., (+A) | +20° 100 |
| A - Min. elongation at fracture (%) (+A) | 35-40 |
| Brinell hardness (HB): (+A) | 230 |
Properties of steel X1NiCrMo31-27-4 (1.4563)
| Resistance to intergranular corrosion: in the delivery condition - yes; in the sensitized condition - yes Steel shal not be applied at a metal temperature lower than -270 ° C |
Mechanical properties
| ReH | Minimum yield strength / Mindestwert der oberen Streckgrenze / Limite d elasticite minimale |
| Rm | Tensile strength / Zugfestigkeit / Resistance a la traction |
| A | Minimum elongation / Mindestwert der Bruchdehnung / Allongement minimal |
| J | Notch impact test / Kerbschlagbiegeversuch / Essai de flexion par choc |
Heat treatment conditions
|
|
