Product Details
Material 904L , 347H Type Stainless Lap Joint Flanges
Standard ASME FACE FF
High Light

347H SS Lap Joint Flange

,

904L SS Lap Joint Flange

,

300 LBS Lap Joint Flange
Leave a Message
Product Description

904L , 347H Lap joint flanges stainless steel high quality ASME FF 300 lbs lap joint flange





Flange Material
Stainless steel
ANSI 304(L); ANSI 316(L), 904L , 347H Lap joint flanges
Duplex steel
ASTM A182; S31803; S32205
Other material
Titanium; C276
Flange Standard
ASME B16.5/16.47
Class150 - Class2500 Flanges
EN1092 (DIN)
PN6-PN40 Flanges
JIS
5K -20 K Flanges
AS
15NB-1200NB Flanges
GOST
PN6-PN40 Flanges
Flange type
1.Welding neck Flange; 2.Slip on 3.Blind flange
4.Long welding neck flange 5.Lap joint flange 6.Socket welding
7.Threaded flange 8.Flat flange
Flange size
1/2" to 80"; DN15-DN2000
Our Certificates
SIL,GB/T45001-2020 IDT ISO45001:2018,GB/T9001-2016 IDT ISO9001:2015
We welcome customized OEM flanges according to customer's requirement





904L / 347H SS Lap Joint Flange ASME FF 300 LBS Lap Joint Flange 0



904L / 347H SS Lap Joint Flange ASME FF 300 LBS Lap Joint Flange 1



Introduction of Flange:

Application:

Used for the connection between the tube end in chemical, construction, water supply, drainage, light and heavy industrial, refrigeration, sanitation, plumbing, fire protection, electrical, aerospace, shipbuilding and other infrastructure projects

Type:

Welding Neck(WN), Plate(PL), Slip On(SO), Blind(BL), Socket Welding(SW),

Threaded(THc), LapJoint(LJ), Long Welding Neck(LWN)



Widely Used Material for Plate Flange:

Stainless Steel: A182 F304/310/316/317/321/347

Carbon Steel: A105

Alloy Steel: A182 F5/F9/F11/F22/F51/F53 INCONEL600 625 825



Common Flange Standard:



NO. FLANGE STANDARD SIZE PRESSURE RATING TYPES
1 ANSI/ASME FLANGE B16.5 1/2"-24"

LBS: 150 300 400 600 900

1500 2500

 SO.WN,SW,TH,LJ,BL
2 ORIFICE FLANGE B16.36 1"-24" LBS: 300 400 600 900 1500 2500 SO,WN,TH
3

LONG WELDING NECK

FLANGES B16.5

 1/2"-24" LBS: 150 300 400 600 900 1500 2500 LWN
4 ASMEB16.47-A(MSS FLANGE) 26"-60" LBS: 150 300 400 600 900 WN,BL
5 ASME B16.47-B(API FLANGE) 26"-60" LBS: 75 150 300 400 600 900 WN,BL
6 AWWA C207 FLANGE 4"-120" TABLE 2,3,4 CLASS B&D SO,BL
7 API 590 FIG.8 FLANGE B16.48 1/2"-36" LBS: 150 300 400 600 900 1500 2500 FIG.8
8 SPACER AND BLANK B16.48 1/2"-36" LBS: 150 300 400 600 SPACER AND BLANK
9 BS 4504 FLANGE DN10-2000 PN: 2.5 6 10 16 25 40 CODE: 101 111 112 113 105
10 SABS 1123 FLANGE DN10-600 KPA: 600 1000 1600 2500 4000 SO.WN,SW,TH,LJ,BL
11 JIS B2220(KS B1503) FLANGE DN10-1500 5K 10K 16K 20K 30K 40K SO.WN,SW,TH,LJ,BL
12 GOST 12820/1-80 DN15-1200 PN: 1 1.6 2.5 4 6.3 10 SO,WN
13 AS 2129 FLANGE DN15-1200 TABLE: D E F H SO,BL
14 NS FLANGE DN15-800 PN: 6 10 16 40 SO,BL
15 VSM FLANGE DN15-200 PN: 6 10 16 SO,WN,BL
16 DIN FLANGE DN10-4000

PN: 1 2.5 6 10 16 25 40 64 100

160 250 320 400

 SO.WN,SW,TH,LJ,BL
17 EN1092 PL DN10~DN600 PN6 PN10 PN16 PN25 PN40 PN63 PN100 TH SO WN BL



904L / 347H SS Lap Joint Flange ASME FF 300 LBS Lap Joint Flange 2
