A524 A106 Grade Seamless Stainless Steel Tubing , Max 0.21% Carbon MS Seamless Pipe
Product Details
seamless steel tube
,seamless mild steel pipe
Product Name : ASTM A524 Carbon Steel Seamless Pipes are Low Carbon Steel Pipes with max 0.21 % carbon content
ASTM A524 Specification
ASTM A524 Carbon Steel Seamless Pipes are Low Carbon Steel Pipes with max 0.21 % carbon content with combination of 0.90-1.35 % manganese. These Pipes are also known as mild steel pipes and tubes.
ASTM A524 Pipesare low-cost Pipes easy to form and shape. These pipes are manufactured as per
ASTM Specification and commercially referred as cs pipes or ms pipes. Low Carbon Steel Pipes are not as hard as hig carbon steel pipes,Though carburizing can increase its surface hardness.
ASTM A524 Properties
| Chemical Properties | |||||||||
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
| max 0.21 | 0.10-0.40 | 0.90-1.35 | 0.035 | 0.035 | – | – | – | – | – |
| Mechanical Properties | |||||||||
| Yield Strength | Tensile Strength | Elongation A5 min | |||||||
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage | ||||
| 414 | 586 | 60 | 30 | ||||||
| Equivalent Designation | |||||
| DIN | EN | BS | NFA | ASTM | ASME |
| – | – | – | ASTM A524 – | ASME SA 524 – | – |
Tube Ends
All tubes are supplied with clean, square cut ends.Deburring and/or chamfering can be carried out on request.
Tube surface
Tubes are supplied normally without anti-corrosive treatment, but anti-corrosive treatment is available and is carried out on request.
Protection
- Black and Bare
- External Varnished with Black or Clear LAcquer
Mill test certificate
- MTC is issued in accordance with EN 10204.
Labelling
ASTM A524 Carbon Steel Seamless Pipes delivered direct from our mill is labeled in accordance with automotive standard, ie with both alphanumeric and bar code information. Customer specific data can be added on request.
ASTM A524 Carbon Steel Seamless Pipes Pictures
-
