14CRMOV6-9 Alloy Steel Seamless Pipes Structural Alloy Chromium Molybdenum Vanadium
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Alloy Or Not | Is Alloy | Surface Treatment | Galvanized,customerized,black Painted |
|---|---|---|---|
| Application | Boiler Pipe,Fluid Pipe | Standard | API |
| Outer Diameter(round) | 22 - 530 Mm | Grade Group | Cr-Mo Alloy |
| Shape | Round Section Mild Steel Pipe | Product Name | ASTM A213 T11 T22 Seamless Alloy Steel Pipe For Boiler |
| Type | Boiler Tube | Usage | Oil Gas Sewage Transport |
| High Light | alloy steel seamless tubes,seamless alloy steel tube |
||
Product Description
What's the15CDV6 , 14CrMoV6-9 , Alloy Steel
Trade Name :Alloy Steel
Standard : 15CDV6 , 14CrMoV6-9 , 1.7734 , 1.7735 , 1.8521
Alloy Steel 15CDV6 specification and Standard , Alloy Steel 15CDV6 Chemical Composition ,Alloy Steel 15CDV6 , SEW Alloy Steel 15CDV6 Mechanical Properties? Alloy Steel 15CDV6 manufacturer
Alloy Steel 15CDV6 Chemical Composition :
| Standards | Steel Grade | |||||||||
| Chemical composition % | ||||||||||
| C: | Mn: | Si: | P: | S: | Cr: | Mo: | V: | Ni: | Cu: | |
| 15CDV6 - 15 CDV 6 - E15CDV6 - E 15 CDV 6 Chemical composition | ||||||||||
| AIR 9160 | 0.12 - 0.18 | 0.8 - 1.1 | <0.20 | <0.020 | <0.015 | 1.25 - 1.50 | 0.8 - 1.0 | 0.2 - 0.3 | - | - |
| 12CrMoV6-9 - 12 CrMoV 6-9 - 1.7734 - 7734 Chemical composition | ||||||||||
| LW | 0.12 - 0.18 | 0.8 - 1.1 | <0.20 | <0.020 | <0.015 | 1.25 - 1.50 | 0.8 - 1.0 | 0.2 - 0.3 | - | - |
| 14CrMoV6-9 - 1.7735 Chemical composition | ||||||||||
| DIN | 0.11 - 0.17 | 0.8 - 1.0 | <0.25 | <0.020 | <0.015 | 1.25 - 1.50 | 0.8 - 1.0 | 0.2 - 0.3 | - | - |
| 15CrMoV5-9 - 1.8521 Chemical composition | ||||||||||
| DIN | 0.13 - 0.18 | 0.8 - 1.1 | <0.4 | <0.025 | <0.030 | 1.20 - 1.50 | 0.8 - 1.1 | 0.2 - 0.3 | - | - |
| 15CrMoV5-10 - 15 CrMoV 5-10 - 1.7745 Chemical composition | ||||||||||
| DIN | 0.10 - 0.16 | 0.4 - 0.9 | 0.15 - 0.35 | <0.025 | <0.015 | 1.10 - 1.40 | 0.9 - 1.1 | 0.20 - 0.35 | <0.25 | <0.25 |
Alloy Steel 15CDV6 in heat-treated state AIR 9160C:
| Mechanical properties - bars | |||
| Size | <16mm | 16 - 25mm | 25 - 70mm |
| Tensile Strenght Rm (MPa) | 980 - 1180 | 1080 - 1280 | 1080 - 1280 |
| Yield point Re (MPa) | >780 | >930 | >930 |
| Elongation A (%) | >12 | >10 | >10 |
| Hardness (HB) | 291 - 350 | 321 - 380 | 321 - 380 |
| Impact strenght KCU | >6 | >8 | >6 |
Our company can supply the following grade's goods
Hot Rolled and forged bars In Grade : 15CDV6 , 1.7734 , 14CrMoV6-9 , 1.7735 , 15CrMoV5-9 , 1.8521
Forgings and ringgs in Grade : 15CDV6
Seamless Steel Boiler Tubes In 15CDV6
