Natural Color Carbon Steel Buttweld Fittings KS / JIS Standard SCH10 XXS Thickness

Place of Origin China
Brand Name Best
Certification API /CE / TUV/ ISO
Model Number 1/2''-48''
Minimum Order Quantity 1 pcs
Price 11 usd/pcs
Packaging Details Wooden cases, Pallets or as customer's requirements
Delivery Time 5-8 working days
Payment Terms L/C /TT
Supply Ability 100000Ton/Year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Carbon Steel/Stainless Steel /Alloy Steel/Duplex Steel Technics Butt Welding /Forged
Type Elbow/Tee/Reducer Size 1/2''-96'' DN15-DN1800
Thickness Sch10---xxs Certificates API/CE/ ISO /TUV
Third Inspection BV/SGS Color Natural
High Light

stainless steel 316 pipe fittings

,

stainless steel pipe joints

Leave a Message
Product Description

Product Name :Carbon Steel Butt-Weld Fittings Approved: Korea – TK Bend Mexico – Tenaris/Riga





KS /JIS Standard :

Wrought Carbon Steel Butt Weld Pipe Fittings

1) 90 Elbow, 45 Elbow (SPP/SGP, 7.9T, STD, X-S)

2) 180 Elbow, Cap (SPP/SGP)

3) Tee (SPP, SGP / 7.9T, STD, X-S)

4) Reducer (SPP, SGP / 7.9T, STD, X-S)

5) 90 Elbow, 45 Elbow (Sch40, Sch80, Sch120, Sch160)

6) 180 Elbow, Cap (Sch40, Sch80, Sch120, Sch160)

7) Tee (Sch40, Sch80, Sch120, Sch160)

8) Reducer (Sch40, Sch80, Sch120, Sch160)



Wrought Stainless Steel Butt Weld Pipe Fittings



1) 90 Elbow, 45 Elbow (Sch5s, Sch10s, Sch20s)

2) Tee (Sch5s, Sch10s, Sch20s)

3) Reducer(Sch5s, Sch10s, Sch20s)

4) 180 Elbow, Cap (Sch5s, Sch10s, Sch20s)

5) Lap Joint (Stub End)





1.Product information of steel elbow

Carbon Steel Butt-Weld Fittings

1/2″ – 60″ STD, XH
Schedules 20, 40, 60, 80, 100, 120, 160, XXH
90’s
45’s
Tees
Conc. Red
Ecc. Red
– Red Tee’s
Red 90’s
Caps
Return Bends
Crosses
– Stub Ends
(ASA & MSS)
Laterals
3R 90’s
5R 90’s
Generic: Korea
Malaysia
Israel
India
Taiwan
Approved: Korea – TK Bend
Mexico – Tenaris/Riga







Name Elbow
Size

Seamless(SMLS) Elbows : 1/2"-24" ,DN15-DN600

Butt Welded Elbows (seam) :24”-96",DN600-DN1800

Type

LR 30,45,60,90,180 degree SR 30,45,60,90,180 degree

1.0D, 1.5D, 2.0D, 2.5D, 3D,4D,5D,6D,7D-40D.

Thickness SCH10,SCH20,SCH30,STD SCH40, SCH60, XS, SCH80., SCH100, SCH120, SCH140, SCH160, XXS
Standard ASME,ANSI B16.9;
DIN2605,2615,2616,2617,
JIS B2311 ,2312,2313;
EN 10253-1 ,EN 10253-2
Material ASTM

Carbon steel:ASTM A234WPB,,A234WPC,A420WPL6,A420WPL3

MSS SP75 WPHY42/46/52/56/60/65/70

Stainless steel:ASTM A403 WP304,304L,316,316L,321. 1Cr18Ni9Ti, 00Cr19Ni10,00Cr17Ni14Mo2, ect.
Alloy Steel:A234WP12,A234WP11,A234WP22,A234WP5,A420WPL6,
DIN Carbon steel:St37.0,St35.8,St45.8
Stainless steel:1.4301,1.4306,1.4401,1.4571
Alloy steel:1.7335,1.7380,1.0488(1.0566)
JIS Carbon steel:PG370,PT410
Stainless steel:SUS304,SUS304L,SUS316,SUS316L,SUS321
Alloy steel:PA22,PA23,PA24,PA25,PL380
GB

10#,20#,20G,23g,20R,Q235,16Mn, 16MnR,1Cr5Mo,

12CrMo, 12CrMoG, 12Cr1Mo

Surface treatment Transparent oil, rust-proof black oil or hot galvanized
Packing In wooded cases or pallets, or as for clients' requirements
Applications Petroleum, chemical, machinery, boiler,electric power, shipbuilding, papermaking, construction, etc
Certification API CE and ISO 9001:2008
Third part inspect BV,SGS,etc accept
Delivery time 7- 15 days after Purchase Order ,have stock ~
Special design as your drawing
Test Direct-reading Spectrograph,Hydrostatic testing machine,
X-ray detector,Ultrasonic flaw detector,Magnetic particle
detector,etc
Equipment Press machine ,Bending machine,Pushing Machine,electric bevelling machine Sand-blasting machine,etc



Production experience



manufactrure about 25 years



2:Butt Welding Fittings in the following forms


 Elbows 45o and 90o – long radius is standard; short radius is also available
 Return bends 180o – long radius is standard; short radius is also available
 Reducers – concentric and eccentric
 Tees – equal and reducing
 Caps
 Stub ends – Type B, to MSS SP-43
Butt welding fittings can be supplied in either seamless or welded construction and are covered by
specification ASTM A403M (or ASTM A815M for Duplex grades) and ASME B16.9.



3: Welded Butt Welding Fittings Weights – ASTM A403M & ASME B16.9
