EN-PN 10285 3 PE Coated Pipe , Epoxy Lined Carbon Steel Pipe Gas / Water Use

Place of Origin China
Brand Name Best
Certification API/CE/TUV/ISO
Model Number 1/2''-48''
Minimum Order Quantity 1 Tons
Price 450 usd/ton
Packaging Details Bare Packing, Seaworthy Packing or As Required
Delivery Time 10~120 (according to the order quantity)
Payment Terms L/C, T/T
Supply Ability 100000Ton/Year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Standard EN-PN 10285. Grade Gruop 3PE Coated Steel Pipes
Thickness 4 - 18 Mm, 4-18mm Out Diameter 355.6-1229mm
Surface PE/2PE/3PE Keyword Epoxy
Usage Oil/gas/water Pipe,structure Production Year 2018
High Light

coated steel tube

,

epoxy coated gas pipe

Leave a Message
Product Description

Product Name : EN-PN 10285. Extruded three-layer polyethylene and polypropylene coating on steel pipes Wirh 3PE coated steel pipes



Extruded three-layer polyethylene and polypropylene coating on steel pipes

In our offer there is the anticorrosive, external, extruded, three-layer, polyethylene/polyethylene coating on steel pipes. The coating technology allows to obtain the anticorrosive three-layer polyethylene/polyetylene coating, which consist of:



- epoxy layer,


- copolymer layer (bonding agent),


- polyethylene/polypropylene layer



The coating is applied on steel pipes of diameters from 159 mm to 1420 mm and length from 6 m to 18m.
Properties of applied coatings comply with the following standards:



- EN-PN ISO 21809, DIN 30670,


- DIN 30678,


- NFA 49-710,


- EN-PN 10285.





The anticorrosive coating consists of the following layers:



- epoxy layer of minimum thickness of 80 μm,


- copolymer layer of minimum thickness of 250 μm,


- polyethylene layer of minimum thickness between 1,8 mm and 3,7 mm or polypropylene layer of minimal thickness between 1,8 mm and 2,5 mm.



We supply coated steel pipes in diameter from 159 mm to 1420 mm and length from 6 m to 18 m. We provide coating services with reference to pipes delivered by our customers.





Coating grade Coating type Coating thickness depending on the pipe outer diameter [mm]
    159 – 273 323,9 – 457 508 – 559 610 – 762 813 – 1420
Polietylenowa N-n, S-n 2 2,2 2,5 2,5 3
N-v, S-v 2,7 2,9 3,2 3,2 3,7
Polipropylenowa standardowa 2 2,2 2,2 2,5 2,5






- high adherence of the coating to the pipe,
- guaranteed long lasting anticorrosive protection of underground pipelines for minimum 50 years,
- 100% protection of weld zone of coated longitudinally and spirally welded pipes,
- suitability for bending of coated steel without damaging the insulation layer.



Extruded three-layer polyethylene and polypropylene coating on steel pipes
